2.05 InputWiringSpecications
ESAB Cutmaster 100 Power Supply Input Cable Wiring Requirements
Input voltage Freq
Power
Input
Suggested Sizes
Volts Hz kVA
I
max
I eff
Fuse
(amps)
Flexible
Cord (Min.
AWG)
Flexible
Cord
(Min. mm
2
)
3
Phase
400 50 18.7 27 24 32 10 6
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTE!
Refer to Local and National Codes or local authority having jurisdiction for proper wiring
requirements.
The suggested sizes are based on exible power cable with power plug installations. For
hard-wired installations refer to local or national codes.
I
1
max is taken at TDC rated minimum duty cycle.
I
1
eff is taken at TDC 100% rated duty cycle.
