ESAB CUTMASTER 100
OPERATION 300X5397
4T-16
Type Torch: SL100 With Shielded Tip Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff
Plasma Gas
Press
Flow (CFH) Pierce Pierce Height
Inches
mm
(Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0,250 6,4
9-8212
124
100
110
2,80
0,180
4,6 75 5,2 130 390
0,4 0,200
5,1
0,375 9,5 9-8212 127 100 75 1,90 0,180 4,6 75 5,2 130 390 0,5 0,200 5,1
0,500 12,7 9-8212 132 100 50 1,30 0,180 4,6 75 5,2 130 390 0,6 0,200 5,1
0,625 15,9 9-8212 136 100 30 0,75 0,180 4,6 75 5,2 130 390 0,8 0,200 5,1
0,750 19,0 9-8212 140 100 18 0,45 0,190 4,8 75 5,2 130 390 2,0 0,225 5,7
1,000 25,4 9-8212 147 100 10 0,25 0,190 4,8 75 5,2 130 390 NR NR NR
Type Torch: SL100 With Shielded Tip Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches
mm
(Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0,250 6,4 9-8212 121 100 110 2,80 0,125 3,2 75 5,2 130 390 0,5 0,200 5,1
0,375 9,5 9-8212 125 100 60 1,50 0,150 3,8 75 5,2 130 390 0,8 0,200 5,1
0,500 12,7 9-8212 132 100 35 0,90 0,150 3,8 75 5,2 130 390 1,0 0,200 5,1
0,625 15,9 9-8212 137 100 20 0,50 0,150 3,8 75 5,2 130 390 2,0 0,225 5,7
0,750 19,0 9-8212 144 100 15 0,40 0,190 4,8 75 5,2 130 390 NR NR NR
1,000 25,4 9-8212 154 100 8 0,20 0,190 4,8 75 5,2 130 390 NR NR NR
Type Torch: SL100 With Shielded Tip
Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches
mm
(Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0,250 6,4 9-8212 120 100 120 3,05 0,180 65 4,5 105 360 0,2 0,225 5,7
0,375 9,5 9-8212 128 100 65 1,65 0,180 65 4,5 105 360 0,4 0,225 5,7
0,500 12,7 9-8212 130 100 45 1,15 0,180 65 4,5 105 360 0,5 0,225 5,7
0,625 15,9 9-8212 135 100 30 0,75 0,180 65 4,5 105 360 0,8 0,225 5,7
0,750 19,0 9-8212 140 100 25 0,65 0,180 65 4,5 105 360 1,0 0,225 5,7
1,000 25,4 9-8212 148 100 10 0,25 0,190 65 4,5 105 360 NR NR NR
NOTE!
* Gas pressure shown is for torches with leads up to 25’ / 7.6 m long. For 50’ / 15.2 m
leads, refer to Section "Set Operating Pressure" on page <?>.
** Total ow rate includes plasma and secondary gas ow.
