SECTION 2 DESCRIPTION
Part Number
EPP-362,
460V,
60Hz,
0558011314
EPP-362,
380V CCC,
50Hz,
0558011315
EPP-362,
400V CE,
50Hz,
0558011316
EPP-362,
575V,
60Hz,
0558011317
Output
(100 %
duty cycle)
Voltage 200 VDC
Current range DC (marking) 10A to 36A
Current range DC (cutting) 30A to 360A
Power 72KW
Open Circuit Voltage (OCV) 360 VDC 364 VDC 360 VDC 360 VDC
Input
Voltage (3-phase) 460 V 380 V 400 V 575 V
Current (3- phase) 109 A RMS 134 A RMS 128 A RMS 88 A RMS
Frequency 60 Hz 50 Hz 50 Hz 60 Hz
KVA 88.7 KVA 88.5 KVA 88.6 KVA 87.7 K VA
Power 83.7 KW 85.1 KW 84.7 KW 84.0 KW
Power Factor 94% 96% 96% 96%
Input Fuse (recommended) 150 A 175 A 175 A 125 A
Weight - lbs (kg) 1130 (514) 1130 (514) 1140 (518) 1125 (512)
2.2 Specications
The EPP-362 power source is designed for mechanized plasma cutting and marking applications. It can be used
with other ESAB products such as the PT-36 torch along with the m3 gas interface, a computerized gas regulation
and switching system.
• 25 to 360 amperes cutting current range and as low as 10 for marking.
• Forced air-cooled
• Water-Cooled IGBTs
• Internal Coolant Circulator
• Solid-state DC power
• Input voltage protection
• Thermal switch protection for IGBTs and input rectier
• Top lifting rings or base forklift clearance for transport
