ESAB ESP-150 - 2 Description; Equipment; Specifications

17
ESP-150 Plasmarc
TM
System
This versatile, all encompassed heavy duty water cooled plasma
cutting and gouging system is ideal for manual and mechanized
applications.
• Greaterproductivity-highspeedcuttingofmostmetals
fromgaugethicknessto2”(50mm)thickplate
• Versatility-230/460/575voltthree-phaseinput
• Greatervariation-adjustableoutput-25to150amps
• Built-InWaterCooler-simpliesmaintenance,lesshook-
up, no wiring issues, no extrahoses. Water ow is con-
trolledwithpowersupply
• WatercooledTorchPT-26
• Leathersheathwrappedtorch-protectstorchleadsfrom
abrasionandmoltenmetal
• Cutswithair,nitrogen,argon-hydrogenmixturesornitro-
gen-hydrogenmixtures
• Built-InCNCinterfaceprovideseasyconnectionofauto-
mationapplications
• Torchdesignprovidesperfectelectrodecentering-pro-
videslongertiplifebyminimizingthepossibilityofdou-
ble-arcing
• Torchspare parts kitsupplied witheach outt - ample
supplyofsparepartstominimizedowntimeatnoaddi-
tionalcost
• Thermal overload switches  -  prevents damage if unit
overheatsduetoinsucientairow
• Linevoltagecompensation
• Automatic intermittent cutting  -  additional capability,
permits continuous cutting of grates, expanded metal,
heavyscreenmaterial,etc.
• Wheelsandcylinderrack-allprovidedstandardforpor-
tabilityandgreaterutilizationatnoadditionalcost
• Idealforplasmagouging
• Threeyearwarrantyonconsole
• OneYearwarrantyontorch
Torch
PT-26 - 70°, 90° or In-Line
Specications
Input Current and Input Voltage at Rated Load
...............................................112/56/45 amps, 230/460/575 Vac, 60 Hz, 3 Ph
Output Rating
90% duty cycle ......................................................................... 150 amps @ 120 V
100% duty cycle ......................................................................140 amps @ 120 V
Open circuit Voltage ........................................................................................ 370 vdc
Dimensions ............................................................................ w = 21.75 in. (552mm)
..................................................................................................h = 31.5 in. (800mm)
...................................................................................................d = 40 in. (1016mm)
Weight ..................................................................................................766 lbs. (348 kg)
SECTION 2 DESCRIPTION
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period
that you can weld at a cer tain load without overloading. The duty cycle is
valid for 40°C.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection
against penetration by solid objects or water.
2.0 Description
The power source is supplied with coolant and instruction
manual.
2.1 Equipment
