ESAB ESP-150 - 4 Operation; Controls and Indicators; Section 4 Operation

33
1 Topping up the coolant
2 Level indicator for the coolant
3 Connection for return cable
4 Ampere and Voltmeter
5 Connection for torch
6 Mains voltage switch
7 Switch for gas
8 Current setting control
9 Indicator lamps
1
2
3
4
5
6
7
8
9
SECTION 4 OPERATION
4.0 Operation
This section provides descriptions of the power source controls and general operating procedures plus, some tips
on cut quality.
4.1 Controls and Indicators
