SECTION 6 REPLACEMENT PARTS
ITEM QTY PART NO DESCRIPTION SYMBOL
1 1 0558002680M PANEL FRONT
2 1 0558002683Y PANEL TOP
3 1 0558002681Y PANEL SIDE LEFT
4 1 0558002682Y PANEL SIDE RIGHT
5 1 0558002678M PANEL BASE
6 1 0558002806
CONTROL PANEL TOP ASSY
(Includes Items 7 thru 10)
7 1 680718 CONTROL PANEL TOP SHELL
8 1 0558003773 PANEL CONTROL SILKSCREENED
9 1 0558003775 PC BOARD - STATUS LIGHTS SLBD
10 1 0558003780 SWITCH ROTOR DPST 600V 25A ROS
11 1 0558004052 SWITCH TOGGLE 3 POS DPDT 15A 125V OSS
12 1 951474 SEAL SWITCH BLACK
13 1 0558003776 POTENTIOMETER 15K 2W CCP
14 1 673999 POTENTIOMETER SHAFT LOCK
15 1 0558003777 KNOB
16 1 0558003778 MAT RUBBER
17 1 0558004053 GROMMET RUBBER
18 1 0558003772 VOLTMETER DC (0-500 VOLTS) VM
19 1 0558003769 AMMETER DC (0-150 AMPS) AM
20 1 0558004054 TERMINAL OUTPUT ASSY WORK
To Next Page
