SECTION 6 REPLACEMENT PARTS
ITEM QTY PART NO DESCRIPTION SYMBOL
43 1 0558002803
HIGH FREQUENCY ASSY
(Includes Items 44 thru 70)
44 1 0558002804M PANEL HIGH FREQUENCY ASSY
45 1 30845M PANEL DIVIDER
46 1 30859 AUTOTRANSFORMER HIGH FREQUENCY HFATR
47 1 0558007469 TRANSFORMER HIGH FREQUENCY HFTR
48 1 0558007163 CAPACITOR .002uF 10KWV C18A
49 1 0558007470 CAPACITOR 2500pF 15KV C18B
50 1 677905 SPARK GAP ASSY SG
51 2 2062161 CIRCUIT BREAKER 5A CB1,2
52 2 182W15 FUSE HOLDER
53 1 82W43 FUSE 1A 250V F3
54 1 96W22 FUSE SLO-BLO 3.2A 250V F4
55 1 30813
TORCH CONNECTION PANEL ASSY
(Includes Items 56 thru 58)
56 1 634090 ADAPTOR SPECIAL
57 1 58V75
ADAPTOR BULKHEAD LH B/A-W*F
1/4NPTM
58 2 0558006292 ELBOW STREET 90 DEGREE 1/4NPT
59 Not Used
60 1 997830 RECEPTACLE 5 POLE J6
61 1 58V58 ADAPTOR BULKHEAD B/I-G*F 1/4NPTM
62 1 33033
ADAPTOR BULKHEAD B/A-W*M
1/4NPTM
63 1 674592 SWITCH SNAP ACTION SPDT 15A 125V ISW
64 1 674971 PC BOARD - HF FILTER FBD2
65 1 0558004069 CAPACITOR 10uF 370VDC C34
66 1 0558004071 RESISTOR 220K OHM 1W R23
67 1 0558004088 RELAY 3PDT 240VAC 28VDC 10A GFIR
68 1 56997963 PC BOARD - VOLTAGE DIVIDER
69 1 0558002996 BRACKET VDR
70 4 950972 CAPACITOR .022uF 1600VDC C15,C16,C20,C21
To Next Page
