63
SECTION 6 REPLACEMENT PARTS
ITEM QTY PART NO DESCRIPTION SYMBOL
71 1 0558002689M BOX PC BOARD
72 1 0558004085 PC BOARD - CONTROL CBD
73 1 0558004086 PC BOARD - LOGIC LBD
74 1 0558004087 CAPACITOR 1500uF 50VDC C25
75 1 0558004090 RELAY TIME DELAY DPDT 120VAC 10A TDR
76 1 17111220 RESISTOR 2K OHM 0.25W R50
77 1 0558004088 RELAY 3PDT 240VAC 28VDC 10A PFR
78 5 0558004089 RELAY DPDT 24VAC 10A SCSR,OSR,CDR,ACR,FR
79 1 17140310 RESISTOR 10K OHM 2W R28
80 1 0558004068 CAPACITOR .01uF 250VAC C13
