SECTION 6 REPLACEMENT PARTS
ITEM QTY PART NO DESCRIPTION SYMBOL
81 1 0558006906
TRANSFORMER / BRIDGE ASSY
(Includes Items 82 thru 99)
82 1 0558004076
TRANSFORMER MAIN
(Includes Items 83 and 84)
MTR
83 2 0558004084 FUSE LINK 150A 250V F1,2
84 3 0558004075 SWITCH THERMAL 180C MTRTS1,2,3
85 1 0558004074
INDUCTOR
(Includes Item 86)
IND
86 1 0558004075 SWITCH THERMAL 180C INDTS1
87 1 680379
BRIDGE ASSY
(Includes Items 88 thru 92)
BR
88 5 950703 DIODE FORWARD 1200V 85A D1,D2,D3,D4,D4A
89 3 680452 RECTIFIER SILICON CONTROLLED 1200V SCR1,2,3
90 1 950711 SWITCH THERMAL 194F BRTS1
91 3 0558004068 CAPACITOR .01uF 250VAC C31,32,33
92 3 950065 VARISTOR METAL OXIDE 420VAC 160J MOV1,2,3
93 1 0558004073
FILTER NETWORK ASSY
(Includes Items 94 thru 98)
94 4 0558004069 CAPACITOR 10uF 370VDC C10,C11,C12,C14
95 4 0558004071 RESISTOR 220K OHM 1W R10,R11,R12,R17
96 5 17280010 RESISTOR 10 OHM 100W R13,R14,R15,R16,R18
97 1 17280210 RESISTOR 1K OHM 100W R19
98 1 17145410 RESISTOR 100K OHM 2W R32
99 1 674970 PC BOARD - SCR GATE FILTER FBD1
100 1 680381 TRANSFORMER CONTROL CTR
101 3 0558004068 CAPACITOR .01uF 250VAC C26,C29,C30
102 1 0558010711 CONTACTOR PILOT ARC 40A 24VAC PAC
103 1 0558004070 RESISTOR 470 OHM 2W R26
104 1 950627 CAPACITOR 4200uF 350VDC C35
105 1 17315247 RESISTOR 4.7K OHM 12W R6
106 2 0558004069 CAPACITOR 10uF 370VDC C17,C19
107 2 0558004068 CAPACITOR .01uF 250VAC C27,28
108 1 17145422 RESISTOR 220K OHM 2W R22
109 2 0558000447 CAPACITOR 1900uF 450VDC C24,24A
110 2 17225310 RESISTOR 10 OHM 8W R36,37
To Next Page
