67
SECTION 6 REPLACEMENT PARTS
ITEM QTY PART NO DESCRIPTION SYMBOL
112 1 0558010710 CONTACTOR MAIN 90A 24VAC MC
113 1 0558004070 RESISTOR 470 OHM 2W R25
114 1 0558004081 LUG GROUNDING GND1
115 1 9680911
TERMINAL BOARD ASSY 230/460/575V
(Includes Item 116)
TB
116 10 672065 TERMINAL STRAP
117 1 672227M BRACKET MOUNTING TERMINAL BOARD
118 1 30941
CAPACITOR BANK ASSY
(Includes Items 119 and 120)
119 9 0558004066 CAPACITOR 60uF 370VDC C1-C9
120 9 0558004067 RESISTOR 330K OHM 0.5W R1-R9
121 1 0558003760 MODULE POWER SUPPLY 24V
122 1 17175413 RESISTOR 133K OHM 2W (In-line / Violet Wire) R29
123 1 0558004072 SHUNT ASSY SH
124 1 0558004068 CAPACITOR .01uF 250VAC C22,23
125 1 0458918880 REED SWITCH RSW
126 1 0558000292 HEAT EXCHANGER
127 1 0558002686M PANEL TOP AIR EXIT CHAMBER
128 1 186W91 GROMMET RUBBER 2-5/8” I.D.
129 1 0558002688 PLATE MOUNTING CAPACITOR BANK ASSY
130 1 0558002808M BAFFLE LEFT
To Next Page
