ESAB ESP-200 - 3.7 Coolant Installation

34
ELECTRIC CURRENT IS HAZARDOUS.
IT IS IMPORTANT TO HAVE A GOOD EARTH GROUND CONNECTED
TO THE WORKPIECE OR CUTTING TABLE.
WARNING
Commercial Antifreeze Will Cause Torch To Malfunction.
Use special torch coolant. P/N 156F05
Due to high electrical conductivity, DO NOT use tap water or com-
mercial automotive type antifreeze for torch cooling. A specially
formulated torch coolant is REQUIRED. This coolant also protects
from freezing to –34 degrees C. Operating the unit without coolant
will cause permanent damage to the coolant pump. Check coolant
level frequently.
CAUTION
Remove coolant ll cap at front console and ll coolant tank with 4 gallons
(15 liters) of plasma torch coolant, P/N 156F05 (one gallon).
Do not ll above indicated maximum level.•
Reinstall cap.•
Coolant Fill Cap
SECTION 3 INSTALLATION
3.7 Coolant Installation
