ESAB ESP-200 - Page 49

49
SECTION 4 OPERATION
Material
Type-Thickness
in.(mm)
Current
(Amps)
Travel
Speed
ipm(M/m
Shield Gas
Type/Pressure
psi(bar)
Cutting
Height
in.(mm)
Pierce
Height
in.(mm)
Plasma Gas
Type/Pressure
psi(bar)
Start Gas
Type/Pressure
psi(bar)
Arc
Voltage
(Volts)
AL - 1/4 (6.4) 200 180 (4.6) 3/8 (9.6) 3/16 (4.8) 151 N
2
- 30 (2.07) N
2
- 35 (2.4) Air - 65 (4.48)
AL - 3/8 (9.6) 110 (2.8) 155
AL - 1/2 (12.7) 70 (1.8) 159
AL - 3/4 (19) 55 (1.4) 1/2 (12.7) 1/4 (6.4) 170
AL - 1 (25.4) 30 (.76) 177
SS - 1/4 (6.4) 200 165 (4.2) 3/8 (9.6) 1/4 (6.4) 148 N
2
- 30 (2.07) N
2
- 35 (2.4) Air - 85 (5.86)
SS - 3/8 (9.6) 105 (2.7) 3/16 (4.8) 149
SS - 1/2 (12.7) 90 (2.3) 150 Air - 65 (4.48)
SS - 3/4 (19) 45 (1.1) 1/2 (12.7) 1/4 (6.4) 159 Air - 45 (3.1)
SS - 1 (25.4) 20 (.50) 169 Air - 65 (4.48)
SS - 1/2 (12.7) 200 50 (1.27) 1/2 (12.7) 3/8 (9.6) 163 N
2
- 30 (2.07) H-35 - 52 (3.6) N
2
- 85 (5.86)
SS - 5/8 (15.8) 47 (1.2) 5/16 (8) 162
SS - 3/4 (19) 32 (.8) 3/8 (9.6) 169
SS - 1 (25.4) 17 (.43) 175
AL - 1/4 (6.4) 200 155 (3.9) 3/8 (9.6) 5/16 (8) 146 N
2
- 30 (2.07) H-35 - 52 (3.6) N
2
- 65 (4.48)
AL - 3/8 (9.6) 120 (3) 1/4 (6.4) 148 N
2
- 45 (3.1)
AL - 1/2 (12.7) 110 (2.8) 5/16 (8) 155
AL - 3/4 (19) 60 (1.5) 1/2 (12.7) 3/8 (9.6) 166 N
2
- 85 (5.86)
AL - 1 (25.4) 40 (1.01) 169
200 Amp Data (PT-19XLS and PT-600) continued
NOTES: SS - Stainless Steel, AL - Aluminum
Stainless Steel 3/8” (9.6mm) and thinner is NOT recommended for H-35 plasma gas - heavy dross
Pilot Arc -- HIGH
