SECTION 7 REPLACEMENT PARTS
Item No Qty Part Number Description Circuit Symbol
1 1 56997963 Board, PC Arc Voltage PCB1
2 1 674969 Filter Board PCB2
3 1 37232 Hose Assembly – Plasma Gas
4 1 37233 Hose Assembly – Shield Gas
5 1 952026 Term Block 7pos 25A 12—18AWG TB5
6 2 952624 Transducer Pressure 4—20mA TD1,2
7 1 673085 Switch Micro SPDT 25A 250V SCR ISW
8 1 0558001952 Manifold Assembly
9 1 37234 Hose Assembly – Water Supply
10 1 37235 Hose Assembly – Water Return
11 1 32281 Enclosure
12 1 37230 Busbar Torch Connection TB3
13 1 0558001297 Spark Gap Assembly
14 1 Ref. Busbar – Pilot Arc TB1,2
15 1 Ref. Busbar – Pilot Arc TB1,2
16 1 37250 Rector Assembly – High Frequency T2
17 1 36682 Wire Kit – Plumbing Box
