ESAB MIGMASTER 250 - Page 53

53
SECTION 6 REPLACEMENT PARTS
+ - DENOTES RECOMMENDED ON HAND SPARE PART
- Added "D" Edition, 3/96
*
ITEM QTY PART CKT.
NO. REQ. NO. DESCRIPTION (Figure 6.3) DESIG.
1 1 33186M REAR, PANEL
2 1 2360 5057GY SUPPORT, REEL
3 1 2360 6237 HUB, REEL (See Figure 6.5)
5 1 634519 SWITCH, TOGGLE, 4 PDT S4
6 1 1373 5464 FUSE, 10A, TIME DELAY F1
7 1 634709 HOLDER, FUSE
9 1 2361 2348 24V GEAR MOTOR, 50-675 IPM KSV 4030/182
10 1 2361 2479 KEY, MOTOR SHAFT
11 1 33199M COVER P.C. BOARD
14 1 952939 DRIVE STAND ASSEM. (See Fig. 6.6)
15 1 82F31 WORK CLAMP
16 1 1373 2232 FILTER, CHOKE / INDUCTOR L1
17 1 951649 POWERCORD
18 1 1373 0583 BUSHING, TERMINAL TP
19 2 676701 TERMINAL ASS'Y., OUTPUT
20 1 97W63 STRAIN RELIEF
21 8' or 10' 95195024 GAS HOSE
1 11N22 NIPPLE
1 136Z08 NUT 5/8-18M RH
1 950731 CLAMP
22 6 13732230 CAPACITORS
23 1 13736738 COPPER BUSBAR CAPACITOR STRAPS (+)
1 13736739 COPPER BUSBAR CAPACITOR STRAPS (-)
+ -
+ -
+ -
*
