ESAB MIGMASTER 250 - Page 54

54
ITEM QTY. PART CKT.
NO. REQ. NO. DESCRIPTION (Detail "B" FAN) DESIG.
2 2 99511916 DIODE, SILICON, STRAIGHT POLARITY D1, D2
3 4 1373 0680 INSULATOR, COLLAR
4 4 1373 0681 INSULATOR, SHOULDER
5 2 1373 1597 WELDMENT, RESISTOR
6 2 1373 0378 DIODE, SILICON, REVERSE POLARITY D3, D4
9 1 951939 BLADE, FAN
10 1 1373 2226 MOTOR, FAN M1
11 1 63311886 HEX NUT 8-32
12 1 13736737 FAN BRKT (torque 19 lbs. max)
13 2 13736733 HEATSHRINK RECTIFIER
14 1 672225 STANDOFF
15 1 23610005 RECTIFIER END BOARD
FIGURE 6.4 MIGMASTER 250 FAN & CAPACITOR BANK
6
4, 3
5
2
11,10, 9
2
6
SECTION 6 REPLACEMENT PARTS
12
13
14
15
