6 MENUS
6.1 Menu overview
The A2--A6 Process Controller (PEH) software is
divided into several menus. The program structure
is described in the overview below.
MAIN MENU
S SET S Heat input per cm S Welding current
S Wire feed speed S Arc voltage S Travel speed
S Preset indicators
WELDING SETUP
S Arc start method S Type of weld finish
S Welding direction S Regulation method
S Wire type S Wire material S Wire size
PRESET SYSTEM MENU / DISPLAY MENU /
ERROR LIST
Menus that are not accessible by the user
+
MAIN MENU
Direction Y
Start Direct
STOP WELDING
WIRE DATA
Regulation CA
PRESET SYSTEM MENU
WELDING SETUP
