9 ERROR LIST
9.1 Error codes
M1.3 Overheating Stop W ait until temperature has fallen
Wire feed motor (Motor 1)
M1.1 Tacho fault Stop Check wire feed unit / gearbox / tacho
M1.2 Current too high Stop Check wire feed
T ravel motor (Motor 2)
M2.1 Tacho fault Stop Check travel motor / gearbox / tacho
M2.2 Current too high Stop Check travel motor / gearbox
Welding power source (T1)
T1.01 Communication error Stop Check cables and connections
T1.51 Incorrect welding voltage Stop Check joint preparation
T1.52 Incorrect current Stop Check joint preparation
T1.53 Unsuccessful start Stop Check stick--out and welding parameters
T1.54 Current limit Stop Welding short--circuited / Cure short--circuit
T1.55 Thermostat / overheating Stop W ait until temperature has fallen
T1.57 Arc extinguished Stop Check wire feed
Inputs / outputs
No cooling water
(inlet K22 open)
*
(Flashing)
Display
Stop Check if the gas is flowing or if the limit
switch is open.
No gas flow
(inlet K23 open)
*
(Flashing)
Stop Check gas pressure
* Inputs are activated by using settings in menu “PRESET SYSTEM MENU”.
10 ORDERING SPARE PARTS
Spare parts are ordered through your nearest ESAB representative, see back cover.
When ordering spare parts, please state machine type and number as well as desig -
nation and spare part number as shown in the spare parts list on page 36.
This will simplify dispatch and ensure you get the right part.
