Escea EF5000 - Fitting the Fascia

630298_3 EF5000 Installation Guide - US
15.0 Fitting the Fascia:
Before fitting the fascia, the hooks must be attached using the screws provided. Ensure the
two wires connecting the fascia to the fire are securely connected, as per section 11.0.
The EF5000 Stainless Steel fascia is attached to the combustion box by four ‘hooks’ on the
corners of the fascia.
15.1 Line up the hooks with the receptacles on the Outdoor Fire pictured below, and push the
fascia into position.
When you have pushed the fascia in as far as it will go, briefly push down on the fascia to
secure the fascia into position.
‘V’ in bracket to face down
