CHAPTER 3 – INSTALLING YOUR CABINET
4. Finally lock the top module to the bottom module by using 2 countersink screw M4
3.2 Installing SPD-3/4AX
3.2.1 List of Parts
The following parts are included in your packaging:
Quantity No. Parts
SPD-3AX SPD-4AX
1. Plastic Screws 16 pieces 16 pieces
2. Hexagonal Bolt M8 x 20 7 pieces 8 pieces
3. Stainless Steel Flat Washer for M8 7 pieces 8 pieces
4. Stainless Steel Spring Washer for M8 7 pieces 8 pieces
5. Pan Head Screw M4 x 12 3 pieces 4 pieces
6. Stainless Steel Flat Washer for M4 3 pieces 4 pieces
7. Wrench/Spanner No.13 1 piece 1 piece
8. Phillips Head Screwdriver 1 piece 1 piece
To Next Page
