ANNEX B - MANUAL FOR THE MEASURING BAR
1 SETTING THE MEASURING BAR
Take size L from the solar panel. Set size L on the
Measuring bar (= 1st handle to 3rd handle).
Turn the Measuring bar so that the handles face down.
4
Set size A with a tape measure.
A = recommended distance between the panels
Place the units at the correct
distance from each other. Align
the units. Use multiple Measuring
bars for this.
L
L
A
12
L
A
L
