ANNEX D - GROUNDING, BONDING AND LIGHTNING PROTECTION
15
1 SELECTION DIAGRAM
LPS = lightning installation
LPL = lightning protection level
URL QR CODE: https://www.esdec.com/nl/kennisportal/
Watch
[SCAN QR]
Risk analysis in
accordance with
NEN-EN-IEC 62305-2
LPS needed?
LPS present?
Installaon within
50 cm of LPS?
Bond to LPS in accordance
with the required LPL in
cooperaon with
lightning specialist.
Install LPS according to
the required LPL in
cooperaon with the
lightning specialist.
Get advice to create a safe
area for PV by means of
Air-terminaon rods
in cooperaon with
lightning specialist.
Overvoltage protecon
in accordance with NPR8110
Proceed with the installaon
in accordance with NEN1010
(NPR5310 part 712-6.3
NEN EN IEC 62305)
yes
no
yes
no
yes
no
Delivery
Oplevering- en
controlerapport PV
installaes Techniek
Nederland en Holland Solar
Esdec oplever- en/of
inspecechecklist
[SCAN QR]
Delivery and inspecon
report PV installaons
Technology Netherlands
and Holland Solar
Esdec delivery and/or
inspecon checklist
[SCAN QR]
