ESDEC FLATFIX WAVE - Assemble Wind Deflector A to the Field; 1 ASSEMBLE THE ROOF SUPPORTS UNDER WIND DEFLECTOR A; 2 ASSEMBLE 2 CONNECTOR PINS TO WIND DEFLECTOR A; 3 ASSEMBLE WIND DEFLECTOR A ON THE UNIT WITH CONNECTOR PINS

09
9 ASSEMBLE WIND DEFLECTOR A TO THE FIELD
4 SLIDE WIND DEFLECTOR A AGAINST THE PANEL
FRAME AND BEND THE FLANGE UNDER THE FRAME
3 ASSEMBLE WIND DEFLECTOR A ON THE UNIT WITH
CONNECTOR PINS
1. Hook the outer connector pin into the hole of the unit.
2. Hook the middle fastening pin into the hole of the high
base.
3. Squeeze the springs to shorten the connector pin.
2 ASSEMBLE 2 CONNECTOR PINS TO WIND DEFLECTOR
A
1 ASSEMBLE THE ROOF SUPPORTS UNDER WIND
DEFLECTOR A
1. Slide the roof supports over the ange of wind deector A.
2. Click the wind deector on the roof supports.
Click!
A B
1. Slide wind deector A against the panel frame on the side
of the eld by inserting the connector pin.
2. Bend the anges under the panel frame by hand.
3. Make sure wind deector A is properly connected to the
panel frame.
