ANNEX E – DISASSEMBLING THE PANELS
1 DISASSEMBLE THE PANELS
1. Place the unlocking tool on the
locking lever.
2. Carefully turn the unlocking
tool downwards so that the
panel latch can be slid back.
3. Slide the panel all the way
back in the direction of the
panel. This unlocks the low side
of the panel.
Click!
4. Lift the panel a few cm and
push the panel backwards out of
the high base elements.
5. Now you can lift the whole
panel.
4 5
18
