Chapter 2 Communication Setup
2.1 Communication Setup
How to Change Communication Settings
1. Activate power, press and hold the
【
◄
】
key on the operating panel
and press the
【
OPERATION SET/ENTER
】
key to enable setting
changes.
The communication interface protocol appears in the temperature
display area, the setting item in the humidity display area and the
setting value in the time display area.
4 8 5
←
Connection interface protocol RS-485
←
Setting item
←
Setting value
2. Select a setting item with the
【
◄
】
and
【
NEXT
】
keys, and change
the setting value with the
【▲】
and
【▼】
keys. After making all
setting changes/checks, press the
【
OPERATION SET/ENTER
】
key.
The setting value is saved in the nonvolatile memory and made active.
Press any other key to interrupt the setting operation and disengage
the setting change operation.
Information displayed while making settings and those meanings are
given below.
Humidity display area: Setting items
Adr : Address
dEL : Delimiter
PAr : Parity setting
StP : Stop bit
LEn : Data length
bPS : Baud rate
Eco : Echo ON/OFF
Ebs : E-BUS protocol
16
