5. RF Certiﬁcation Test

ESP8266 and ESP32 share the same RF certiﬁcation testing process. This chapter takes

the ESP32 RF certiﬁcation test as an example.

The test BIN is ESP32_RF_TEST_BIN_V1.3.1_20180115.bin, and the baud rate is

115200. Follow the instructions in chapter 4 to conﬁgure the serial port and download the

ﬁrmware.

5.1 Wi-Fi certiﬁcation test

1. Choose "wiﬁ Test" in the test conﬁguration section. Choose "TX continue" for the

"Test Mode", set the "WiFi Rate", "BandWidth", "Channel" and "Attenuation", as

shown in the picture below. "Attenuation" indicates the power attenuation in multiples

of 0.25 dB. Users can set the value as required.

2. Click on "start" to send commands. Refer to Table 4-1 for data rates. Click on

"stop" to end the test.

3. Before switching to other channels or data rates, please click on “stop” to

terminate the current transmission.

5.2 BT certiﬁcation test

The BT certiﬁcation test shares the same testing process as the BT test that is

described in the chapter 4.

Espressif

! /!14 19

2018.03
