Programming
Remote Alpha-Numeric Display Network
PROJECT SELECTION
Project Name : _________
Project Description:_________________
Enter number of product:
1 for FCC Class A
2 for FCC Class B
3 for IRC-3
4 for LSS
Enter Number : _________
Project Name: (8 char max) is used to identify a specific project.
Alphanumeric characters - no spaces.
Project Description: (20 char max) provides a description of the project.
Type: defines the fire panel model associated with this project.
For annunciators operating in the IRC-3 and FCC modes, continue with
the next section.
For annunciators operating in the LSS4 mode, continue with the LSS4
Configuration section.
IRC-3(FCC/PCPU) and FCC/DCPU RS-485
Data Line Configuration
Programming notes, RS-485 Data Line Configuration
When connected to an IRC-3 network or an FCC/PCPU data line
(Figure Chapter 2-1 and Figure Chapter 2-2,) each LSRA(-C) requires
one panel address for each 88 messages, with a maximum of 4
consecutive addresses (352 messages) per display. Do not use address
41through 44. Each LSRA(-C) panel address must be configured in
the IRC-3 Data Entry or FCC Compiler Program as a SAN Annunciator
with SAN-COM enabled. Because the SAN-COM function must be
enabled, ONLY DEVICE ADDRESSES 9-96 CAN BE USED. Each
RS-485 connection on the LSRA(-C) is optically isolated.
LSRA(-C) regenerative operation is identical to SAN annunciator
operation in the regenerative mode. Regenerative operation is
programmed using the same steps used to program a regenerative SAN
annunciator, using "906x" to "909x" actions. If multiple addresses are
required when using the IRC-3 or FCC/PCPU annunciator
configuration, ALL annunciator panel addresses, i.e. base address and
up to three additional addresses for a fully configured annunciator,
must be defined as part of the regenerative family. Remember, if
regenerative operation is used on FCC PCPU RS-485 data lines, only
CM2N(-D)s on the same data line may be included in a regenerative
“family.” Refer to the IRC-3 Network Programming Manual P/N
250060 for additional information on regenerative programming.
Programming Notes PCPU Port Configuration
4.6
LSRA Installation, Operation, Maintenance, and Configuration Manual
