Programming
Remote Alpha-Numeric Display Network
PROJECT SELECTION
Enter Project Name : _________
Enter Project Description:_________________
Project Name: (8 char max) is used to identify a specific project.
Alphanumeric characters - no spaces.
Project Description: (20 char max) provides a description of the project.
Type: defines the fire panel model associated with this project.
The type of host system to which the LSRA will be connected is
entered using the respective index number, as shown on the next
screen. Enter a “1” or “2” for Class A or Class B FCC systems,
respectively. Enter a “3” when configuring the annunciator for IRC-3
(or FCC/PCPU) data line operation, and a “4” when configuring the
annunciator for use with an LSS4 panel.
LSRA Installation, Operation, Maintenance, and Configuration Manual 4.5
