E200PS Operation Manual
3
Chapter 1 Product Introduction
1.1 Characteristic
E200PS CNC device is a very suitable for torsional axis shearing machine, providing
solutions for most of the wiggle or gate machine both complete and economy, with high
performance, flexible configuration, compact structure, easy to use, high reliability characteristic:
 Servo control, can realize the backgauge and high accuracy of control block.
 The gap (G-axis) is controllable.
 Unilateral and bilateral location, to improve the positioning precision and reduce screw
clearance.
 The action CUT and EOS is controllable.
 Pneumatic feeding causes to convey the material to be nimble.
 Backgauge can automatic homing.
 Backgauge can be adjusted through the manual keys.
 The pages of SYSTEM PARAMETER and DIAGNOSIS are hidden, requires a specific
password can enter into.
1.2 Operation Panel
E200PS Operation panel is as shown in Figure 1-1.
Figure 1-1 Operation panel
Functions of panel keys are described in Table 1-1.
Table 1-1 Description of key functions
Key
Function Description
Delete key: delete all data in input area on left bottom of displayer.
Enter key: confirm the input content. If no content is input, the key has the similar
function to direction key .
