E200PS Operation Manual
6
2.2 Multi-Step
2.2.1 Background
Now, There are 5 metal materials, need to be processed into three workpieces with different
length, the require as following:
 The first sheet: Length is 100.00mm, Gap is 1.00mm, Distance of retracting is 5.00mm.
 The second sheet: Length is 300.00mm, Gap is 1.00mm, Distance of retracting is
5.00mm.
 The third sheet: Length is 600.00mm, Gap 1.00mm, Distance of retracting is 5.00mm.
2.2.2 Analysis
This operation will edit and save in the 2program, set the following parameters on the
PROGRAM page.
Page
Parameter
Setting
PROGRAM
ST
3
PP
5
1 / 3ST
XP
100.00mm
GP
1.00mm
DX
5.00mm
Repeat Times
1
2 / 3ST
XP
300.00mm
GP
1.00mm
DX
5.00mm
Repeat Times
1
3 / 3ST
XP
600.00mm
GP
1.00mm
DX
5.00mm
Repeat Times
1
2.2.3 Procedure
Step 1 When the E200PS device is electrified, wait a few seconds into the SINGLE page
(Default page).
Step 2 Press to enter PROGRAMS page.
Step 3 Press or arrow key to select 2program, and then press to enter the
NO.2 PROGRAM page.
Step 4 According to the analysis, press the arrow keys and number keys to modify the
corresponding parameters, as shown in Figure 2-2.
