E200PS Operation Manual
7
NO.2 PROGRAM
:Total Step
X= 10.00 G = 10.00
ST: 3 STEP
PP: 5 PIECE
CP: 5 PIECE
Figure 2-2 Multi-Step example configuration
Step 5 Press to enter 1/3ST page, and modify the parameters according to Step4,
the result of modifying is as shown in Figure 2-3.
PROGRAM2 1 / 3ST
:DestPos Of Axis X
X= 10.00 G = 1.00
XP: 100.00 mm
GP: 1.00 mm
DX: 5.00 mm
Cut Length: 80 %
Repeat Times: 1 TIMES
Figure 2-3 Step configuration
Step 6 According to Step 5, modify the parameters on the 2/3ST and 3/3ST pages.
Step 7 Press back to PROGRAM page.
Step 8 Press to run the device, the device will enter the running page.
----End
