Air valves for log boilers with pellet flange
The air valves for a log boiler with pellet flange
for the TWIN burner are different; for boilers
without a burner flange, see page 27.
Prepare air valve shafts
for primary and secondary air
Pull the cotter pin on the spring side.
Remove the washer, the spring and an air valve
from both shafts.
Take both air valves from fuel chamber
Take both shafts, including air valves, from the fuel
chamber.
