45°

Actuators Installation

Actuators

Turn air valve shafts to 45° position

Turn both air valve shafts to the 45° position.

Turn actuator to middle position

Press the button on the actuator to turn the

actuator by hand.

Turn the actuator to the middle position so that the

recess is centred.

Attach brackets to actuators

Fit the brackets to the rear sides of both actuators.

Attach actuators

Press the actuators with the brackets onto both air

valve shafts. Tighten the screws on the brackets.
