6.5.5 ES400 Modules with ETAS RTPRO-PC (Rapid Prototyping)
Fig. 6-20 ES400 Modules with ETAS RTPRO-PC (Rapid Prototyping)
Cable in
Fig. 6-20
Function Order name
1 Power supply and Ethernet cable PC and Daisy
Chain modules
CBEP410,
CBEP4105,
CBEP415,
CBEP4155
2 CAN and FlexRay Y-interface cable CBCF100
Power Supply
Daisy Chain Modules
1
2
CAN
ES581.4
Ethernet
USB2
CAN
ES411
ES413
ES415
ES410
ES420
ES421
ES430
ES432
ES441
