Fig.
8
Whenever
the
pump
is
dismantled
from
the
pipework,
you
will
be
well
advised
to
replace
the
caps
on
the
connectors
to
avoid
residual
liquid
being
spilled.
Before
attaching
the
deliver
y
hose
to
the
plant,
prime
the
metering
pump
by
going
through
the
sequence
shown
in
Fig.
8.
Before
finalizing
the
installation
of
the
dis-
charge
hose,
make
sure
that
the
pump
strokes
will
not
cause
it
to
move
and
bump
into
rigid
bodies.
In
case
of
priming
difficulties,
use
a
normal
syringe
to
suck
liquid
from
the
discharge
nipple
while
the
pump
is
in
operation,
continuing
until
you
actually
see
the
liquid
rise
in
the
syringe.
Use
a
shor
t
length
of
suction
hose
to
connect
the
syringe
to
the
discharge
nipple.
In
case
of
a
pump
equipped
with
an
air
bleed
valve,
unscrew
the
air
relief
valve
B
up
to
all
the
air
in
the
pump
head
will
be
out.
f.
-
T
r
y
to
keep
both
the
suction
and
discharge
hose
as
straight
as
possible,
avoiding
all
unnecessar
y
bends.
g.
-
Select
the
most
appropriate
injection
point
on
a
pipe
of
the
plant
to
be
treated
and
there
fit
a
3/8"
female
steel
gas
thread
connector
(similar
to
BSPm).
This
connector
is
not
supplied
with
the
pump.
Screw
the
injection
valve
to
the
gas
connector
,
inserting
a
gasket
as
shown
in
Fig.
9.
Then
connect
the
discharge
hose
to
the
conical
connector
on
the
injection
valve
and
fix
it
with
the
supplied
tube
nut
G.
The
injection
valve
also
acts
as
no
retur
n
valve
by
means
of
a
cylinder
sleeve
(elastomer
,
standard
supplied
in
V
iton).
N.B.
The
sleeve
D
must
not
be
removed.
3.1
-
INJECTION
VAL
VE
INST
ALLA
TION
DIAGRAM
(Fig.
9)
A
-
Pipework
C
-
Injection
valve
M
-
Conical
connector
for
attaching
the
discharge
hose
N
-
3/8"
female
steel
gas
thread
connector
G
-
Hose
tube
nut
T
-
Polyethylene
hose
D
-
Cylinder
sleeve
(no
retur
n
valve)
Fig.
9
3.2
-
MANUAL
STROKE
LENGTH
ADJUSTMENT
-
(upon
request
only
for
DLXB)
-
press
and
tu
r
n
the
knob
up
to
the
stroke
length
adjustement
required.
