ETC Installation Guide
ColorSource PAR v1.5
ColorSource PAR v1.5 Page 2 of 12 ETC
Environment
The ColorSource PAR operates in ambient temperatures of 0°C–40°C and it
comes with a variable-speed fan.
Electrical
• Operates between 100V and 240VAC at a frequency of 50/60Hz.
• Maximum power consumption is 120W.
• Up to 9 luminaires (15A max) may be linked via power thru connector
(10 luminaires total per circuit) when used with an R20 relay module or
Unison Echo
®
Relay Panel. Consult breaker trip curves when used with
other equipment. Requires power from a non-dimmable source.
Typical power consumption
Note:
The ColorSource PAR is for indoor use only.
Note:
• Maximum recommended ambient operating
temperature: Ta = 40°C (104°F)
• Maximum anticipated external surface temperature
at 40°C ambient: Tmax = 80°C (176°F)
• External temperatures after 5 minutes of full-
brightness operation at 25°C (77°F) ambient:
30°C (86°F)
• External temperature (steady state achieved) at
25°C (77°F): 41°C (106°F)
WARNING:
Disconnect the fixture from power and DMX and allow
it to cool before performing any cleaning and
maintenance.
100V 120V 230V
Idle Power/Current 1.22W/0.026A 1.21W/0.026A 1.14W/0.026A
Direct at Full/Current 107W/1.07A 106W/0.88A 104W/0.46A
