ETC Installation Guide
ColorSource PAR v1.5
ColorSource PAR v1.5 Page 3 of 12 ETC
Installation
Mounting
The ColorSource PAR ships with a standard yoke. An expandable floor stand
yoke is available as an optional accessory. Contact your local dealer for more
information.
Safety cable
The safety cable (or other approved
safety device) must be attached to the
fixture. Attachment loops are
provided on the fixture housing. Take
care to leave as little slack as possible
in the safety cable to avoid catching
the yoke of the fixture.
Connectors
• Power: Two powerCON
®
connectors for power in and thru
• Data (DMX512/RDM): Two five-pin XLR connectors
OR
two RJ45
connectors for data in and thru
Conversion cables are available from ETC. Please contact your ETC customer
service representative and request part number W6538 for RJ45 to female
XLR, and part number W6539 for RJ45 to male XLR.
Note:
This fixture is not Ethernet/data network compatible.
