13-4 Throttle Housing
DISASSEMBLY
Loosen the screws on the throttle housing cover.
Remove throttle housing cover and gasket.
Disconnect throttle cable from the throttle arm
and remove from the throttle housing.
NOTE:
Assembly is in the reverse order of disassembly.
13-5 Steering System
When the steering shaft needs to be repaired, you need to remove three kinds of components: the tie-rods, front wheels
and hub assy. Following the steps to check these components, if broken please change the new one
Screws
To Next Page
