14-4 Hydraulic Brake
This type of brakes are applying in front of two wheels of
RA1
REMOVAL
Raise the front wheels off the ground by placing a jack
or other support under the frame.
Remove the front wheel nuts, washer and wheels.
Please follow the next three steps of right pictures.
Loosen fours nuts as shown in picutre
Then take the wheel out.
you can find two bolts fixed at front hydraulic disk
component.
Loosen these two bolts and you can take out disk component.
After disassembling the wheel, please inspect the disk plate.
If the disk plate needs to be changed, you have to loosen
castle nut to take wheel hub apart.
Bolts
