16-3 Front Fender Removal
To remove the front fender, there are sever trips to indicate
users how to remove it.
1. First picture shows there are two screw, loosen it.
Remove the mounting bolts from the front fender.
Please remove the two screws on the top of the headlight.
Then you can see there is a screw on the tip of the vehicle.
Please remove it.
There is a screw near the suspension as shown in picture.
Bolts
Bolt
Screws
