15-4 Swingarm & Rear Axle Holder
This section is to introduce how to repair the swing-arm,
The following pictures are going to teach you how to
Install the swing-arm.
1. Put the swingarm at proper position as shown in
picture. Two hanger bolts will be used to hold the swing-arm
at right and left side.
2. Tighten a hanger bolt on the right side as shown in
picture.
Hanger bolt Swingarm
Hanger bolt
