Eton ATV8F - MAINTENANCE; Maintenance Data and Schedule

2-2 Maintenance Schedule 2-9 Drive Chain
2-3 Fuel Tube 2-10 Brake System
2-4 Throttle Operation 2-11 Wheels And Tires
2-5 Throttle Cable Adjustment 2-12 Steering Shaft Holder Bushing
2-6 Air Cleaner 2-13 Toe-In
2-7 Spark Plug
2-1 Maintenance Data
SPECIFICATION
SPARK PLUG
SPARK PLUG GAP 0.8 mm
RECOMMENDED SPARK PLUGS NGK CR8E
THROTTLE LEVER FREE PLAY 5-10 mm
IDLE SPEED 1700±100 rpm
BRAKE LEVER FREE PLAY 15-25 mm
DRIVE CHAIN SLACK 10-25 mm
TOE-IN 5±10 mm
TORQUE VALUES
SPARK PLUG 12-19 N.m
TIE-ROD LOCK NUT 35-43 N.m
ENGINE OIL 1.4 Liter (1.2Liter for change)
GEAR LUBRICATION OIL 750cc (650cc for change)
17
2. MAINTENANCE
2-1 Maintenance Data 2-8 Idle Speed
