● 5 mm bolt and nut
5 N.m (3.5 lbf.ft)
● 6 mm bolt and nut
10 N.m (7.2 lbf.ft)
● 8 mm bolt and nut
22 N.m (16 lbf.ft)
●10 mm bolt and nut
35 N.m (25 lbf.ft)
●12 mm bolt and nut
55 N.m (40 lbf.ft)
ENGINE
● Cylinder head nut
38 N.m (27.4 lbf.ft)
● Spark plug
12 N.m (8.9 lbf.
ft)
● Cylinder head bolt
15 N.m (10.1 lbf.ft)
● Alternator bolt
8 N.m (5.9 lbf.ft)
FRAME
● Handlebar upper holder bolt
24 N.m (17.7 lbf.ft)
● Throttle housing cover screw
4 N.m (2.9 lbf.ft)
● Steering shaft nut
50 N.m (36.9 lbf.ft)
● Steering shaft holder bolt
33 N.m (24 lbf.ft)
● Wheel rim bolt
18 N.m (13.3 lbf.ft)
● Tie rod lock nut
35 N.m (25.8 lbf.ft)
● King pin nut
40 N.m (29 lbf.ft)
● Handlebar lower holder nut
40 N.m (29.5 lbf.ft)
● Front wheel bolt
24 N.m (17.7 lbf.ft)
● Front axle castle nut
40-60 N.m (30-45 lbf.ft)
● Front brake arm nut
4 N.m (3.0 lbf.ft)
● Rear brake arm nut
7 N.m (5.2 lbf.ft)
● Rear axle castle nut
40-60 N.m (30-45 lbf.ft)
● Rear wheel bolt
24 N.m (17.7 lbf.ft)
● Exhaust muffler mounting bolt
30 N.m (22.1 lbf.ft)
● Engine hanger bolt
30 N.m ( 22 lbf.ft)
● Rear axle holder bolt
90 N.m (65 lbf.ft)
● Swing arm pivot nut
90 N.m (65 lbf.ft)
● Rear shock absorber mounting nut
45 N.m (33 lbf.ft)
1-5 Torque Values
STANDARD
Nuts, Bolts Tightness
Perform periodical maintenance in accord with the Periodical Maintenance Schedule Check if all
bolts and nuts on the frame are tightened securely.
Check all fixing pins, snap rings, hose clamp, and wire holders for security.
