Eton ATV8F - Engine and Chassis Specifications

7
1-3 EngineSpecifications
Type
4 Stroke，Single Cylinder, Water cooled
Displacement 287.2c.c.
Bore and Stroke 75 mm x 65 mm
Compression 10.0:1
Maximum Hp 20ps / 6500
Maximum Torque (Nm/rpm) 24.6 Nm / 5000
Carburetor
Ignition DC-CDI
Starting Electric
Lubrication Auto oil injection
Transmission Automatic (C.V.T. V-belt + Reverse)
CHASSIS
Overall Length
1815mm
Overall Width
1062mm
Overall Height
1130mm
Wheel base
1193mm
Ground Clearance
150mm
Dry Weight
225Kg
Fuel Tank Capacity
12L
SUSPENSION
Front
Double A-Arm & Adjustable
Rear
Swing Arm & Adjustable Shock
BRAKES
Front
Front Hydraulic Disc*2
Rear
Rear Hydraulic Disc*1
TIRES
Front
21x7-10
Rear
22x10-10
PRESSURE【 psi ( kgf/cm2)】
Front
12(0.8)
Rear
12(0.8)
COLORING
Specifications subject to change without notice.
