3. Screw another hanger bolt on the left side as shown in
picture. But do not tighten it. Let the cross-section of bolt
and cross-section of hole in the same plane nearly.
4. Tighten the nut
NOTE: If you make a wrong assembly procedure, it will cause:
1. A damage of bearings
2. The main frame will be extended at the area of assembly swim arm (Unalignment).
Hanger bolt
