5-10 Air Cleaner
Removal
Loosen the clamp strip of air cleaner and carburetor,
and then remove the vapor hose.
Loosen the clamp strip of air cleaner, and then
remove the air cleaner vapor hose.
Remove the air cleaner (4 bolts).
Installation
Install the tank in the reverse order of removal.
Cleaning air cleaner element
Remove the air cleaner cover (4 catch hooks).
Remove element mounting screw.
Loosen the clamp strip of air cleaner element, and
then remove the air cleaner element.
Clean the element with non-flammable or high-flash
point solvent and then squeeze it for dry.
Caution
Never use gasoline or acid organized solvent to
clean the element.
Soap the element into cleaning engine oil and then
squeeze it out. Install the element onto the element
seat and then install the air cleaner cover.
Clamp
4 bolts
Clamp
4 hooks
1 screw
Clamp
