25809-02A
18 - Assembly Procedures
Parts needed:
Left Door (box 4)
(2) Hinge bushings
NOTE: Wiring deleted from
illustration for clarity.
Place the Hinge Bushings into the
hinge holes (top and bottom).
Carefully lower the door hinge pins
into the bushings, being careful not
to bend the friction tabs.
To Next Page
