12
26868-01A
Installation - Final Assembly
Final Assembly
Make sure the air filter is in place on top of
the ballast drawer. It simply sits on the
drawer, over the air slots, and is held in
place by airflow when the unit is running.
The arrow on the filter should point down.
Put the Front Access Panel in place and lock
with the Access Panel Key.
Note: You may have a few extra screws left
over.
ACCESS PANEL
FILTER
