26868-01A
4
Installation - Hardware Inventory
Nylon Floating
Bearing
Quantity 4
Hinge Pin,
5/16” x 2 1/32”
Quantity 2
Hinge Pin Locking Clip
Quantity 2
Clevis Fork,
M10 Long
Quantity 2
Bronze Bushing, 10mm
Quantity 2
Clevis Pin, 10mm
Quantity 2
Retaining Ring
Quantity 2
Phillips Screw, #10 x 1/2”
Quantity 8
Phillips Screw, #10 x 1”
Quantity 8
Hardware Inventory
Use the utility knife to cut open the hard-
ware bag. Remove the hardware. In addi-
tion to some touch-up paint, a phone type
(RJ-11) cable and pillow, make sure you
have the following items.
Safety Goggles
Quantity 1
Access Panel Key
Quantity 1
WARNING
Always wear protective eyewear when unit is on.
Failure to may result in severe burns or
longterm injury to the eyes.
