EUCHNER CES-I-BR Series User Manual

25
2510145-02-07/18 (translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-BR-.-C07-…
EN
11.2. Technical data of actuator CES-A-BTN-C07-…
Parameter Value Unit
min. typ. max.
Housing material PBT plastic
Dimensions 42 x 25 x 18 mm
Weight 0.03 kg
Ambient temperature - 40 - + 70 °C
Degree of protection IP 65/IP 67/IP 69/IP 69K
Installation position Active face opposite read head
Power supply Inductive via read head
11.2.1. Dimension drawing
Active face
NOTICE
Ì Two safety screws M4x20 included.
Ì Covers are included.
