EVAstream Electrical connections - PCB Settings www.evaoptic.com28
Attachments
Overview of the EVAstream Control Print
Function Type Port Type Function
Fan 24Vdc - 1 2 + Fan 24Vdc
ppm output 2 - 3 4 + ppm output 2
ppm output 1 - 5 6 + ppm output 1
piezo 4 LED 12Vdc - 7 8 + piezo 4 LED 12Vdc
piezo 4 switch sw 9 10 sw piezo 4 switch
piezo 3 LED 12 Vdc - 11 12 + piezo 3 LED 12 Vdc
piezo 3 switch sw 13 14 sw piezo 3 switch
piezo 2 LED 12 Vdc - 15 16 + piezo 2 LED 12 Vdc
piezo 2 switch sw 17 18 sw piezo 2 switch
piezo 1 LED 12 Vdc - 19 20 + piezo 1 LED 12 Vdc
piezo 1 switch sw 21 22 sw piezo 1 switch
dmx G (shield) G 23 24 G dmx G (shield)
dmx in/out - 25 26 - dmx in/out
dmx in/out + 27 28 + dmx in/out
24Vdc in - 29 30 - 24Vdc out
24 Vdc in + 31 32 + 24 Vdc out
